Features & Benefits
Integrated three-zone design: preheating, heating (≥350℃, residence time ≥5 min), and cooling, for stable drying, sterilization and depyrogenation.
PLC + HMI control system for accurate programmable setting, monitoring and operation of heating and running parameters.
Stepless adjustable conveyor speed and variable-frequency controlled laminar air velocity for stable and flexible production.
Automatic variable-frequency air balancing between zones to ensure uniform airflow and temperature.
Full temperature monitoring system: supports setting, real-time display, recording, printing, and fault alarm.
Whole process protected under Class 100 laminar air flow, ensuring sterile production environment.
Fully designed and manufactured in compliance with GMP standards.
Automatic conveying to downstream equipment, enabling smooth line integration.
Application
Suitable for drying, sterilization and depyrogenation of pharmaceutical glass containers such as vials, ampoules, oral liquid bottles and similar containers.
Mainly applied in pharmaceutical sterile preparation production lines requiring high-temperature depyrogenation.
Ideal for automatic, clean and GMP compliant bottling and filling production lines.
Specitications
|
Voltage |
380V/50Hz |
|
Total Power (kw) |
53 |
|
Electric Heating Tube |
Far-infrared electric heating quartz tube; Quantity:15 |
|
Application |
Ampoule, Vial, Oral liquid container |
|
Fresh Air Inlet Velocity (m3/min) |
3,000 |
|
Wind pressure (mpa) |
50～450 |
|
Speed of Conveyor Belt (mm/min) |
30-350 |
|
Air Velocity Control |
Variable frequency speed regulation |
|
Temperature Adjustable Range(°C) |
60～350 |
|
Uniformity of Temperature(°C) |
±15 |
|
Cleanness Grade (class) |
100 |
|
Noise (DB) |
≤70 |
