Features & Benefits
Product Overview: High-precision fully automatic machine for liquid and sauce special-shaped bag packaging. Equipped with PLC, touch screen, servo motor and PID temperature control, it adopts back sealing and fits composite film, delivering intelligent, stable and high-efficiency packaging.
Fully Automatic Integrated Operation: Automatically completes bag making, metering, filling, sealing, slitting and counting. Optional batch number printing enables unmanned continuous production for higher efficiency.
High-Precision Constant Temperature Control: Servo motor ensures accurate bag length adjustment. PID temperature control keeps error within ±1℃ for smooth, firm and leak-proof sealing.
Complete Safety Protection Mechanism: Supports intelligent alarm and auto-stop for door opening, temperature deviation and low air pressure, preventing defective products and equipment failure.
Stable Sealing & Strong Material Adaptability: Professional back sealing fits composite film perfectly. Tight and uniform sealing effectively avoids liquid leakage and improves product shelf life.
User-Friendly & Stable Performance: Simple touch screen parameter setting and accurate detection. Low failure rate and strong compatibility support standard and customized fluid packaging.
Application
This equipment is professionally used for quantitative special-shaped bag packaging of various liquids, sauces and slurries, with wide applicability in food, pharmaceutical, chemical and cosmetic industries.
Food Industry: Suitable for special-shaped bag packaging of sauces, beverages, edible oil, seasonings, honey and various dairy liquids.
Pharmaceutical Industry: Applicable for packaging oral liquid, medicinal slurry and topical liquid medicine, fully complying with pharmaceutical production hygiene and precision packaging standards.
Chemical & Cosmetic Industry: Ideal for sealed packaging of cosmetics lotion, essence, skin care slurry and various fine chemical liquid products.
Specitications
| ITEM | HDK-320 |
| Measuring Scope | 1 - 20ml |
| Bag Size: Length (L) | 30 - 180 mm |
| Bag Size: Width (W) | 20 - 60 mm |
| Packing speed | 20 - 35 bags/min |
| Dimension ( L* W * H ) | 1120 * 1570 * 2120 mm |
| Weight | 720 kg |
| Total Power | 220V / 50 - 60HZ / 3KW |
| Gas source | 0.6MPA |
Options
The machine supports multiple customizable optional configurations to meet personalized production and market demands:
Videos
HDK-320 Special-shaped Bag Packing Machine | Automatic Irregular Pouch Packaging Machine
HDK Fully Automatic Vertical Packaging Machine
