Features & Benefits
GMP Compliant Structure: The whole machine adopts food-grade 304 stainless steel, fully complying with GMP production standards, ensuring hygienic and safe packaging.
Stable Bag Forming: Built-in film offset correction system and roll film alignment device, effectively correct film deviation and guarantee consistent bag-making stability.
Premium Packaging Quality: Servo motor film pulling system provides stable tension, realizing firm sealing and neat, aesthetic finished bags.
User-Friendly Multilingual Operation: Intuitive touch screen with default Chinese and English languages, supporting customized language settings for global users.
Intelligent Fault Protection: Equipped with automatic film breakage identification system, triggering alarm and automatic shutdown to reduce material waste and machine failure loss.
High Intelligent & Reliable Control: Adopts premium brand electrical components and PLC control system, featuring high intelligence, fast response speed and high production efficiency.
Application
Applicable Materials: Specially designed for diversified powder packaging, widely suitable for milk powder, flour, seasoning powder, medicinal powder, protein powder, coffee powder and other fine powder products.
Applicable Industries: Ideal for food, pharmaceutical, health care and seasoning industries, meeting standard automatic powder packaging demands.
Specitications
|
Model |
HDCK-P-2-4 |
HDCK-P-3-10 |
HDCK-P-4-16 |
|
Lanes |
2-4 Lanes |
3-10 Lanes |
4-16 Lanes |
|
Bag width |
20-70mm |
20-95mm |
20-105mm |
|
Film width |
Max:300mm |
Max:600mm |
Max:900mm |
|
Sealing Type |
Back seal |
||
|
Packing speed |
20-40Bags/Lane/Min |
||
|
Measuring |
Long screw/short screw/short screw with cup |
||
|
Cutting Type |
Straight cutting/Zig zag cutting/Round cutting/Die-cut |
||
|
Bag length |
50mm-180mm |
||
|
Power Supply |
50HZ/220V/3.5kw |
50HZ/220V/5.5kw |
50HZ/220V/7.5kw |
|
Dimension(mm) |
1800*1120*3300 |
1800*1430*3350 |
1800*1740*3450 |
|
Weight |
about 400kg |
about 600kg |
about 950kg |
Options
