Features & Benefits
32-channel vibration feeding (2×16-channel units) with patented filling part and 3-stage vibration trays; adjustable frequency, even feeding, no material breakage.
Wide applicability: fits tablets (abnormal included), capsules, gels (all types), pills and most solid granules; no parts change for different sizes/shapes.
High dust resistance: original anti-dust sensor + dedusting system (optional dust box); self-adjusting sensor sensitivity, stable operation in heavy dust.
Accurate counting: intelligent sensor eyes + photoelectric counting; bottling error below national standard.
High automation: no-bottle no-count/fill; auto-remove defective bottles/broken tablets; fault self-diagnosis and alarm.
Optional: special hopper to prevent jamming (fast small-mouth bottling); sealed dust-proof design.
Easy operation: Chinese/Chinese-English menu, HMI touch screen; stores 10 groups of parameters for quick recall.
Easy maintenance: tool-free quick disassembly; easy to clean/change parts; simple training for operation.
Compact design: easy to clean; separated vibration trays for longer life and 100% counting accuracy.
Double rail conveyor; air cylinder bottle positioning + diving nozzles, avoiding filling spillage.
High efficiency: up to 120 bottles/min; cGMP compliant; excellent after-sales support.
Application
Ideal for automatic counting and filling of solid preparations, including hard gelatin capsules, softgels, tablets (standard, abnormal), gels (transparent, opaque, abnormal), round pills, and most solid granules.
Suitable for industries requiring high accuracy, high automation and cGMP compliance (e.g., pharmaceuticals, nutraceuticals, food & beverage, etc.), meeting the needs of high-volume production.
Applicable for scenarios requiring stable operation in dust-prone environments, with flexible adaptation to various product types and sizes without parts replacement.
Specitications
|
ITEM |
GS-32 |
|
|
Application |
- |
00-5# capsules, soft gels, ф3-22mm tablets pills special shape tablets, coating tablets，and some other solid granules |
|
Capacity |
- |
40～120 BPM (subject to the type and size of the bottle，as well as the quantity filled per bottle) |
|
Working Range |
pcs |
1-9999 |
|
Size |
mm |
2200*1400*1680 |
|
Material |
- |
SS316+SS304 |
|
Pressed Air Supply |
- |
0.4-0.6 |
|
Net Weight |
kg |
650 |
|
Air Consumption (Clean Air) |
L/min |
150 |
|
Total Power |
kw |
3.8 |
|
Power Supply |
- |
AC220V 1P 50-60HZ |
|
Overall Size |
mm |
1900*3000*1670 |
Options
